How do I put this … the latest revision of the board works. The only thing that I haven’t delved into I2C, but everything that I have tried so far works. Completely. Which is actually extremely rewarding, since this has been a slog for a year plus. Some previous posts to catch you up:
Well all of the problems have been addressed. Vic’s Power and Serial Board works.
A few gratuitous Potato-Cam(tm) pictures
Lets talk about a little pisser of chip to solder at home. The LTC7004 FET driver in a 10-MSOP footprint; 0.02mm gap between the pins. That one took a bit of rework. Apparently my stencil game is not quite up to par. For reference, the resistors to the right are 0805 packages.
